In recent years, with the continuous development of science and technology, intelligence is becoming more and more popular, an intelligent community includes building intercom system, monitoring system, access control system, parking lot system, anti-theft alarm, community broadcast and other systems, with these, an intelligent community is presented in front of people. An intelligent community building intercom part can account for 40% of the intelligent community. While this series of intelligence has brought great convenience to people, there have also been a series of problems and failures, especially the intercom system of residential buildings. With the development, the building system shows a trend of branding, diversification and more intelligent development. The building system changed from ordinary intercom to black and white to color. Color visual system is now the most used in the market, but also the most promising. Now cloud vision shield electronics on several color visual intercom system common problems to find and exclude methods to share with you.
Several common problems of color visual intercom system: the first is that there is no image in the visual extension, which is generally divided into two kinds, the extension blue screen or black screen. The second is the extension can not unlock the problem.
Fault 1, the visual extension appears blue screen without image phenomenon. That means the extension is working, but the images aren't coming through. The first thing to check is the blue screen of the whole unit or a certain household or a few households.
If it is the blue screen of the whole unit, the general problem is in the video line of the host, so first check whether the video line is connected, in the case of good connection, and then check whether the pc line of the host (that is, the video power supply line) in the open screen state voltage reaches more than 16V, (if there is no multimeter at hand, you can lead the host 12V power supply to the PC terminal, if the image is normal, Check whether the PC cable of the video power supply is connected, and whether there is a problem with the video power supply), if it reaches about 16V, the video cable is no problem. Finally check whether the camera is damaged, you can replace it with a good camera, if the problem is solved, it is the problem of the camera.
If there is a blue screen in a single household, first check whether the same blue screen exists in several other households of the same viewfinder, if so, replace the viewfinder or check whether the viewfinder entrance line is connected. If not, first check whether the video line of the visual extension is connected, whether the branch line of the visual adapter is connected, or whether the visual adapter is damaged.
Fault 2, the extension screen is black without image. The extension power supply is not coming.
If the whole unit is black screen, first: check whether the working indicator of the power supply is normal, if normal, please use a multimeter to measure whether the 18V output of the power supply is normal (16V-19V is normal), if the output is not in the normal range, please replace the power supply.
Second: When everything is normal after checking the power supply, please check the power line of the host output to the extension.
If it's a single black screen
First: If there is a black screen in several households of the same viewfinder, please check whether the viewfinder entrance line is connected or replaced.
Second: if the same viewfinder is normal in other households, the plugline on the viewfinder of this extension can be replaced on the viewfinder port of other normal extension, if it is normal, the viewfinder will be replaced; If it still does not work, please check that the extension (replace it with a new extension) or the extension line to the viewfinder is normal.
Fault 3, the whole building extension can not open the lock.
First: check whether the lock is faulty, open the host with the positive pole of the lock line contact the 12V terminal of the host, if the lock is opened, the lock is normal, but also indicates that the line between the host and the lock is normal, if you can not open the lock, check whether the line between the host and the lock is normal, whether the lock is normal.
Second: Replace the host.
Fault 4, single extension can not open the lock.
First: You can replace the extension and check whether there is a problem with the unlocking key of the extension.
Second: Check the line between the extension and the viewfinder (connect the extension directly to the viewfinder) if it can be used normally, it indicates that there is a problem in the branch line or some place short circuit.
The above is the common problem analysis of the building system, which can be referred to by the majority of cloud shield dealer friends.
